Benchtop Air Coil Winding Machine : DETZO DSW-C01FW

DSW-C01FW Benchtop CNC Air-Coil Winding Machine

Applications

The DETZO DSW-C01FW is a specialized system engineered for precision self-bonding wire winding, particularly ideal for producing high-quality air-core coils and inductor coils. This model features an exceptional rapid style-changeover capability, significantly reducing wire replacement and tooling adjustment times to meet the demands of high-mix product development and flexible production. Whether for consumer electronics or specialized applications, the DSW-C01FW ensures robust forming and precise dimensions, making it the premier precision platform for high-efficiency changeovers and all types of related self-bonding coil processing.

Precision Alcohol Bonding Air Coil Winding

Alcohol Bonding: High-Precision Air Coil Forming

Air Coil: Custom Shaped Self-Bonding Process

Air Coil: Precision Inductor Applications

Air Coil: Standard Circular Bonding Process

Air Coil: Multi-layer High Fill-factor Winding

Feature

High-Efficiency Automatic Winding Solution: Equipped with a programmable N.C. control system, this solution combines flexible production design with 999 program step memory. Engineered for industrial environments demanding high efficiency and space optimization, its robust yet simple structure significantly reduces maintenance costs while ensuring long-term operational stability.

Smart Control: Programmable N.C. system with an intuitive interface for easy operation and maintenance.

Rapid Changeover: Unique winding fixture design allows for quick adaptation to various production requirements.

Flexible Production: Supports semi-automatic production modes, providing excellent manufacturing versatility.

Massive Storage: Built-in memory for 999 program steps, significantly reducing setup time between different patterns.

Robust & Simple: Minimalist mechanical structure ensures durability, precise control, and low maintenance overhead.

Space Optimized: Compact footprint design saves factory floor space and allows for flexible plant layouts.

Technical Specifications

No. of Spindle

1 Spindle

Max. Speed

3,200rpm (CW/CCW)

Wire Diameter

Ø0.03 ~ Ø0.50mm

Control System

N.C. Controller

Applicable Wire

Self-bonding
(Alcohol type)

Spindle Motor	AC Motor	Step Angle	0.9°
Traverse Motor	Stepping Motor	Traverse Width	1 ~ 80mm
Traverse Pitch	0.01 ~ 9.99mm	Min. Traverse Unit	0.01mm
Max. Winding Dia.	26mm	Power Supply	1Φ 110/220Vac \| 50~60Hz ±1%
Power Consumption	200W	Machine Weight	70kg ±10
Machine Dimensions	750(L) x 380(W) x 570(H) mm

Optional Accessories

CE Certification

Safety Guard

Wire Breakage Detection

Tailstock Mechanism

Model	DSW-C01FH
	Benchtop Single Spindle CNC Air-Coil Winding Machine (for hot air self-adhesive wire)
